Canal de vídeo de encóderes ópticos

En los vídeos puede conocer mejor nuestra tecnología de encóderes ópticos y decidir qué cabezas lectoras, reglas y herramientas de diagnóstico son las más adecuadas para su aplicación.

Los vídeos de instalación y estudios de aplicación explican también por qué nuestros productos son adecuados para los entornos más hostiles.

Introducción a los encóderes ópticos

Play
An introduction to encoders [en]

An introduction to encoders

A simple introduction to what is an encoder, its benefits and where they are used.
[512 x 288] [18.5MB]

Cabezas lectoras de encóderes ópticos

FORTiS™

Play
Presentamos FORTiS™, la generación avanzada de encóderes lineales encapsulados

Presentamos FORTiS™, la generación avanzada de encóderes lineales encapsulados

Con un diseño robusto y preparados para soportar los entornos más hostiles, los encóderes FORTiS™ combinan la regla de acero endurecido con el sistema de obtención de imágenes a velocidad ultra-alta y procesamiento de señales digital líder del sector. Este sistema de encóder sin contacto introduce unas características de diseño innovadoras, que ofrecen a los instaladores y usuarios ventajas exclusivas respecto a los encóderes encapsulados convencionales. Para más información, vea el vídeo.
[1920 x 1080] [190.8MB]
Play
FORTiS™ enclosed encoders have been rigorously tested [en]

FORTiS™ enclosed encoders have been rigorously tested

Renishaw has decades of experience in the design, manufacture, and operation of metrology products suitable for use within harsh environments such as machine tools. This experience inspired our rigorous testing programme for the FORTiS enclosed linear encoder range, which includes, amongst others, tests for: vibration, seal wear, Ingress Protection (IP), long-term operation in a machine chamber, salt spray (fog), chemical resistance, drop and shock.
[1920 x 1080] [406.7MB]

RESOLUTE™

Play
RESOLUTE™ absolute linear and rotary encoder [en]

RESOLUTE™ absolute linear and rotary encoder

Video introducing RESOLUTE™, a true absolute, fine pitch optical encoder system.
[1280 x 720] [130.5MB]
Play
RESOLUTE™ FS (Functional Safety) [en]

RESOLUTE™ FS (Functional Safety)

RESOLUTE™ FS is a true absolute open optical encoder system certified to the following functional safety standards: ISO 13849:2015 PLd, IEC 61508:2010 SIL2, IEC 61800-5-2:2007 SIL2.
[1280 x 720] [44.6MB]
Play
RESOLUTE UHV (Ultra-High Vacuum) true-absolute optical encoder [en]

RESOLUTE UHV (Ultra-High Vacuum) true-absolute optical encoder

RESOLUTE UHV (Ultra-High Vacuum) true-absolute optical encoder is ideal for UHV applications, including semiconductor device manufacture, wafer handling, scientific research and medical applications.
[1280 x 720] [203.8MB]

EVOLUTE™

Play
EVOLUTE™ absolute optical encoder - fundamentals of operation [en]

EVOLUTE™ absolute optical encoder - fundamentals of operation

No description available
[1280 x 720] [43.5MB]

Instalación

Vídeo de instalación: Instalación ultra-rápida del encóder lineal encapsulado FORTiS™

Vídeo de instalación: Instalación ultra-rápida del encóder lineal encapsulado FORTiS™

Diseño sin contacto combinado con un sistema de instalación por LED, que asegura un procedimiento de instalación más intuitivo y sencillo hasta un 90 %* más rápido que en los sistemas convencionales. Vea las diferencias en el vídeo. (*) depende de la aplicación.
[1920 x 1080] [70.0MB]
Installation video: How to install the FORTiS-S™ enclosed absolute linear encoder [en]

Installation video: How to install the FORTiS-S™ enclosed absolute linear encoder

Learn how to install the FORTiS-S™ (standard) enclosed absolute linear encoder. Please refer to the relevant FORTiS installation guide for more information. The FORTiS encoder series is a next generation enclosed linear absolute encoder for use in harsh environments such as machine tools. Robust, reliable, high-performance position measurement over the encoder's long life is ensured by a range of innovative design features, such as: industry-proven position measurement, non-contact, superior sealing, class leading vibration resistance, easy installation and Advanced Diagnostic Tool.
[1920 x 1080] [87.9MB]
Installation video: How to install the FORTiS-N™ enclosed absolute linear encoder [en]

Installation video: How to install the FORTiS-N™ enclosed absolute linear encoder

Learn how to install the FORTiS-N™ (narrow) enclosed absolute linear encoder. Please refer to the relevant FORTiS-N installation guide for more information. The FORTiS encoder series is a next generation enclosed linear absolute encoder for use in harsh environments such as machine tools. Robust, reliable, high-performance position measurement over the encoder's long life is ensured by a range of innovative design features, such as: industry-proven position measurement, non-contact, superior sealing, class leading vibration resistance, easy installation and Advanced Diagnostic Tool.
[1920 x 1080] [83.5MB]
Installation video: How to install the RESOLUTE™ encoder readhead [gen]

Installation video: How to install the RESOLUTE™ encoder readhead

Language independent installation animation
[1920 x 1080] [25.1MB]
Installation video: How to install the VIONiC™ digital encoder readhead [en]

Installation video: How to install the VIONiC™ digital encoder readhead

No description available
[1920 x 1080] [146.3MB]
Installation video: How to install the QUANTiC™ encoder readhead [en]

Installation video: How to install the QUANTiC™ encoder readhead

No description available
[1920 x 1080] [146.5MB]
Installation video: How to install the Renishaw TONiC™ super-compact digital encoder readhead [en]

Installation video: How to install the Renishaw TONiC™ super-compact digital encoder readhead

Learn how to install the TONiC super-compact digital encoder readhead. Please refer to the relevant TONiC installation guide for more information. The TONiC encoder series is Renishaw’s super-compact, non-contact incremental optical encoder that offers speeds up to 10 m/s and, when combined with the Ti interface, resolutions down to 1 nm for both linear and rotary applications. TONiC systems are quick and simple to install with wide set-up tolerances and calibration at the push of a button. TONiC's dynamic signal processing gives improved signal stability with ultra-low Sub-Divisional Error, high running speeds and compatibility with linear and rotary applications. This makes TONiC suitable for the highest of performance applications where speed and accuracy are crucial. TONiC UHV is available for ultra-high vacuum applications.
[1920 x 1080] [241.1MB]
Installation video: How to install the ATOM DX™ miniature digital encoder readhead [en]

Installation video: How to install the ATOM DX™ miniature digital encoder readhead

The ATOM DX encoder series is Renishaw’s smallest incremental optical encoder with digital output direct from the readhead, providing positional feedback, onboard interpolation, and filtering optics all in a miniature package. ATOM DX incorporates the market proven filtering optical system of the ATOM™ encoder series, and integrates Renishaw’s high-performance interpolation technology, reducing system size and the need for additional adaptors and interfaces. This makes ATOM DX suitable for the most space critical applications where performance cannot be compromised. Available to be used with the ATOM series of linear and rotary scales to meet most application requirements.
[1920 x 1080] [226.2MB]
Installation video: How to install the CENTRUM™ self-centring scale disc [en]

Installation video: How to install the CENTRUM™ self-centring scale disc

CENTRUM™ CSF40 is a stainless steel encoder scale disc. It includes innovative alignment flexures that automatically centre the scale when pushed onto a shaft, providing improved metrology performance. CENTRUM self-centring scale discs are quick and easy to install 'right first time': no additional gauges or set-up devices are required.
[1920 x 1080] [42.2MB]
Installation video: How to install RKLC incremental linear encoder scale [en]

Installation video: How to install RKLC incremental linear encoder scale

The Renishaw RKLC encoder scale is a narrow, low cross-sectional area stainless steel tape scale featuring 20 μm or 40 μm pitch incremental graduations. RKLC scale is installed onto the axis substrate by a self-adhesive backing tape and it is mastered to the machine substrate, giving improved metrology, when the scale ends are rigidly fixed to the substrate. The scale is compatible with Renishaw’s VIONiC™, TONiC™ and QUANTiC™ incremental encoder series.
[1280 x 720] [120.5MB]

QUANTiC™

Play
Introducing the QUANTiC™ encoder series [en]

Introducing the QUANTiC™ encoder series

The QUANTiC™ series of encoders are made for manufacturing industries. The QUANTiC encoders are easy to install with exceptionally wide installation and running tolerances, along with built-in installation and calibration functions. QUANTiC encoders combine high speed interpolation with impressive metrology performance, whilst being compatible with the Advanced Diagnostic Tool, ADTi-100.
[1280 x 720] [61.8MB]

VIONiC™

Play
Serie de encóderes incrementales digitales VIONiC™: diseñados para los diseñadores

Serie de encóderes incrementales digitales VIONiC™: diseñados para los diseñadores

La serie de encóderes digitales VIONiC se ha diseñado expresamente para el usuario final. Por su rendimiento, facilidad de uso y múltiples configuraciones, que le ayudan a optimizar el rendimiento de la máquina, VIONiC está diseñado realmente para diseñadores. Por su diseño de modo de calibración automática intuitiva, las cabezas lectoras VIONiC son también muy fáciles de instalar. La herramienta Advanced Diagnostic Tool (ADTi-100) está disponible para la información de datos del encóder en tiempo real, lo que simplifica las instalaciones y diagnósticos más complicados. Para más información, visite www.renishaw.es/vionic
[1920 x 1080] [189.5MB]

ATOM™

Play
ATOM™ miniature incremental encoder (miniaturisation without compromise) [en]

ATOM™ miniature incremental encoder (miniaturisation without compromise)

Video introducing the ATOM miniature incremental optical encoder. (This version has sound + voiceover).
[1280 x 720] [174.0MB]
Play
ATOM miniature optical encoder system employs unique filtering optics to provide exceptional dirt immunity. [en]

ATOM miniature optical encoder system employs unique filtering optics to provide exceptional dirt immunity.

Video showing the ATOM miniature optical encoder's impressive dirt immunity with live oscilloscope.
[1280 x 720] [209.6MB]

ATOM DX™

Play
An incremental encoder engineered for metrology: Introducing ATOM DX™ [en]

An incremental encoder engineered for metrology: Introducing ATOM DX™

Renishaw’s expert engineers introduce the technology behind the new ATOM DX™ digital encoder. The ATOM DX encoder builds on Renishaw's ATOM™ miniature encoder series, first launched in 2014, and incorporates advanced interpolation technology originally developed for the VIONiC™ and QUANTiC™ digital encoder families. The combination of miniature size, digital quadrature output direct from the readhead and Renishaw's market proven filtering optics create a powerful foundation for the building blocks of a motion system.
[1280 x 720] [184.9MB]

Herramientas de diagnóstico

Play
Introducing the Advanced Diagnostic Tool, ADTi-100 and ADT View software [en]

Introducing the Advanced Diagnostic Tool, ADTi-100 and ADT View software

The QUANTiC™, VIONiC™ and ATOM DX™ series of incremental encoders are quick and easy to install and calibrate without the need for additional tools. However, for applications where more detailed encoder information is required, you can use an optional Advanced Diagnostic Tool ADTi-100, combined with the free downloadable ADT View software, to give real-time encoder feedback for calibration and diagnostics.
[1280 x 720] [50.9MB]
Play
Increasing encoder performance with Advanced Diagnostic Tools (ADTs) [en]

Increasing encoder performance with Advanced Diagnostic Tools (ADTs)

The Advanced Diagnostic Tools, ADTa-100 and ADTi-100, acquire comprehensive real-time data from Renishaw's RESOLUTE™, EVOLUTE™ and FORTiS™ absolute encoders, and VIONiC™, QUANTiC™ and ATOM DX™ incremental encoders. This information is displayed via the user-friendly Renishaw ADT View software interface.
[1280 x 720] [19.6MB]

Reglas de encóderes ópticos

Play
Improved metrology with the substrate mastered RKLC encoder scale [en]

Improved metrology with the substrate mastered RKLC encoder scale

The Renishaw RKLC encoder scale is a narrow, low cross-sectional area stainless steel tape scale featuring 20 μm or 40 μm pitch incremental graduations. RKLC scale is mastered to the machine substrate giving improved metrology when the scale ends are fixed to the substrate. The scale is compatible with Renishaw’s VIONiC™, TONiC™ and QUANTiC™ incremental encoder series.
[1280 x 720] [146.7MB]

Estudios

Play
Aplicación: El encóder encapsulado FORTiS™ mejora la precisión y el rendimiento del rectificado

Aplicación: El encóder encapsulado FORTiS™ mejora la precisión y el rendimiento del rectificado

Después de realizar pruebas y evaluaciones, TGT seleccionó los encóderes encapsulados FORTiS™ de Renishaw para su última serie de rectificadoras de herramientas. La facilidad de instalación y las características innovadoras de los encóderes FORTiS permiten a TGT optimizar el rendimiento de sus máquinas.
[1920 x 1080] [270.1MB]
Play
ATOM™ encoders allow rapid, high-accuracy FPD inspection and repair [en]

ATOM™ encoders allow rapid, high-accuracy FPD inspection and repair

Manufacturing error-free flat panel displays is a challenge, because as display performance improves, manufacturing processes become more complex and panel defects can become more common. Inspection and repair procedures have been developed to ensure that errors have minimal effect on display quality. Renishaw's ATOM encoder system has been integrated into a variable aperture stop design. Precise manipulation of the laser aperture, in the range of 5 - 50 microns (um) in diameter, is vital to ensure successful panel repair. Discover in full how TPC Motion integrated the ATOM series encoder at: www.renishaw.com/tpc-atom
[1280 x 720] [52.8MB]
Play
RESOLUTE™ encoders give focus to big science [en]

RESOLUTE™ encoders give focus to big science

Case study video interview featuring IRELEC's Business Development Manager
[1280 x 720] [239.6MB]
Play
Los encóderes TONiC™ son imprescindibles para la medición y el control de precisión avanzados

Los encóderes TONiC™ son imprescindibles para la medición y el control de precisión avanzados

No description available
[1920 x 1080] [343.9MB]
Play
3DHISTECH integrates encoder technology into its pathology scanner [en]

3DHISTECH integrates encoder technology into its pathology scanner

Located in Budapest, Hungary, 3DHISTECH designs and manufactures one of the world's fastest and highest-capacity autonomous panoramic digital slide scanners – the P1000. The P1000 is a highly accurate scanning microscope that enables large routine pathology labs to capture ultra-high resolution images of medical samples, while operating unmanned for up to 2 days. Building upon 3DHISTECH's successful product range, this new generation of digital slide scanner is the first to have integrated optical and magnetic position feedback encoders for enhanced throughput. With Renishaw's technical support, 3DHISTECH's engineering team were able to specify an encoder for each machine axis and find the appropriate encoder products for their applications. Renishaw's advanced encoders, such as the VIONiC™ series, enable the P1000 to achieve truly market-leading performance.
[1280 x 720] [339.2MB]
